- Atco QUATTRO 16S 4-in-1 Petrol Lawnmower 41cm / 139cc
- Product Pictures
Atco QUATTRO 16S 4-in-1 Petrol Lawnmower 41cm / 139cc - Complete with 5 Year Warranty
The Quattro 16S is a great value 4-wheel, self-propelled lawnmower with a cutting width of 41cm is ideal for working around compact lawns with uneven terrain or sloping areas. Soft-grip handlebars are designed for comfort and have two height settings to accommodate your ideal mowing position.
Specification Atco QUATTRO 16S 4 in 1 Petrol Lawnmower 41cm / 139cc
Powered by Stiga 139cc Autochoke engine
Self-propelled
41cm (16") cutting width
4-in-1 cutting-system - collect, mulch, side-discharge and rear-discharge.
60 L grass collector with indicator to show when full
Handy quick connect washing link
The STIGA ST 140 engine with an automatic choke ensures quick and easy starting, while its OHV engine design provides consistent fuel intake for a smoother mow and a more long-lasting engine, along with the added benefits of fuel-saving and low emissions.
Boasting four cutting modes- collecting, mulching, rear and side-discharge - the versatile Quattro 16S is capable of handling short grass, long grass, and everything in between.
A single lever enables the cutting height to be adjusted through 6 positions ranging from 22mm to 65mm. The useful and capacious 60-litre grass-box is made from fully-collapsible textile fabric for easy storage and has a grass-full indicator, so you can focus on continuous mowing. A washing link allows you to clean corrosive debris quickly from the undercarriage, protecting the mower and extending its lifespan.
The Quattro 16S 4-in-1 is a fabulously popular walk-behind lawn mower at a superbly economical price.
This model is ideal for areas up to 900m2. A 5-year manufacturer's warranty is included with this machine (T&C's apply).
What's in the box
QUATTRO 16S 4in1 Petrol lawn mower
Grass bag
Technical specs Atco QUATTRO 16S 4 in 1 Petrol Lawnmower 41cm / 139cc
General info
EAN/UPC 8008984848900
SKU 2L0432847/AT1
Power
Power 2.2 kW
Power source Petrol
Engine Brand STIGA
Engine model ST 140 OHV Autochoke Powered by STIGA
Displacement 139 cm³
Engine rotation speed 2900 rpm
RPM control Fixed rpm
Starter Recoil
Fuel tank capacity 0.75 l
Engine Oil tank capacity 0.5 l
Suggested working area 300 m
Cutting system
4 in 1 cutting system Yes
Cutting width 41 cm
Deck material Steel
Cutting height adjustment Centralized
Cutting height positions 6 positions
Cutting height range 22 - 65 mm
Drive system
Driving Self-propelled
Traction Rear-wheel drive
Speed forward 3.7 Km/h
Equipment
Collector capacity 60 l
Handlebar type Ergonomic + soft grip
Wheels 200/200mm grooved wheels on ball bearings with soft tread
Front handle Yes
Adjustable handlebar Yes
Foldable handlebar Yes
Washing link Yes
Collector type Hybrid with warn
Vibration and noise data
Guaranteed sound power level (LwA) - dB(A) 95
Measured sound power level dB(A) 94
Measured sound pressure level at operator ear dB(A) 81
Vibration level hand (m/s2) 4
Overall dimensions
Pack weight 29.8 kg
Product length 1500 mm
Product width 660 mm
Product height 1110 mm
Weight 27 kg
Frequently Asked Questions
Should the petrol lawn mower be protected from rain?
All ATCO lawn mowers are IPX4 certified, meaning that they are not damaged by rain. However, it is recommended to keep the lawn mower in a garage or store it indoors. Full information can be found in the instruction manual.
Is this petrol lawnmower already assembled in the box?
The petrol lawn mower is almost fully assembled when you open the box. The main parts have been put together and the remaining elements are easy to assemble. Follow the directions in the instruction manual to ensure the petrol lawnmower is assembled correctly.
How should this petrol lawn mower be cleaned after use?
We recommend cleaning the lawn mower in the normal way after each use. Before washing the lawn mower, we suggest that any residual grass or top soil is removed using the special scraper, which can be purchased separately. Next, the inside of the chassis can be washed with water. Follow the steps described in the user manual.
Which fuel and engine oil are recommended for this petrol mower?
You should use petrol as fuel. In terms of engine oil, we recommend using the specific oil, which can be purchased separately. This will guarantee the best engine performance and optimal lubrication.
What happens to this petrol mower if there are small objects in the garden?
When the lawn mower is in use, you should look out for any stones, pine cones or other small objects which may be on the lawn. These objects could damage the blade and hit nearby objects or people.
How should the oil level be measured on this petrol lawn mower?
To correctly measure the oil level, you need to make sure the petrol lawnmower is on a flat surface, unscrew the cap which has a built-in dipstick for measuring, clean off any oil on the dipstick and reinsert it without screwing it in. Take the dipstick back out and check the level, which must lie between the MIN and MAX values. Top up, if required, and screw the cap back on. Full details can be found in the engine manual.
Barcode / EAN: 8008984848900
Atco QUATTRO 16S 4-in-1 Petrol Lawnmower 41cm / 139cc has a 5 Year Warranty
Atco QUATTRO 16S 4-in-1 Petrol Lawnmower 41cm / 139cc has an exclusive Mower Magic 5-Year Warranty, supplied to you free of charge. To read more about this exclusive warranty, please click here.
